宽度：7.49 mm

• Timer0: 8-bit timer/counter with 8-bit prescaler

• Timer1: 16-bit timer/counter with prescaler,

can be incremented during SLEEP via external

crystal/clock

• Timer2: 8-bit timer/counter with 8-bit period

register, prescaler and postscaler

• Two Capture, Compare, PWM modules

- Capture is 16-bit, max. resolution is 12.5 ns

- Compare is 16-bit, max. resolution is 200 ns

- PWM max. resolution is 10-bit

• 8-bit, up to 8-channel Analog-to-Digital converter

• Synchronous Serial Port (SSP) with SPI (Master

mode) and I2C (Slave)

• Universal Synchronous Asynchronous Receiver

Transmitter (USART/SCI)

• Parallel Slave Port (PSP), 8-bits wide with

external RD, WR and CS controls (40/44-pin only)

• Brown-out detection circuitry for

Brown-out Reset (BOR)

PIC16F73-I/SO控制器8位 7KB 192 RAM 22I/O

PIC16F73-I/SO控制器8位 7KB 192 RAM 22I/O

PIC16F73-I/SO控制器8位 7KB 192 RAM 22I/O

PIC16F73-I/SO控制器8位 7KB 192 RAM 22I/O
