1 Features

1• Industry's Fastest Astable Frequency of 3 MHz

• Available in Industry's Smallest 8-Bump DSBGA

Package (1.43mm × 1.41mm)

• Less Than 1 mW Typical Power Dissipation at 5 V

Supply

• 1.5 V Supply Operating Voltage Ensured

• Output Fully Compatible With TTL and CMOS

Logic at 5 V Supply

• Tested to −10 mA, 50 mA Output Current Levels

• Reduced Supply Current Spikes During Output

Transitions

• Extremely Low Reset, Trigger, and Threshold

Currents

• Excellent Temperature Stability

• Pin-for-Pin Compatible With 555 Series of Timers

2 Applications

• Precision Timing

• Pulse Generation

• Sequential Timing

• Time Delay Generation

• Pulse Width Modulation

• Pulse Position Modulation

• Linear Ramp Generators
